| XJ1800 | ||||
|---|---|---|---|---|
| Print parameter | ||||
| Printhead | Ricoh Gen5 | Ricoh Gen6 | Epson T3200 | Epson I3200 |
| No.of printhead | 3-9 | 3-9 | 5-7 | 6 |
| Max production speed | 90 sqm/h | 120 sqm/h | 150 sqm/h | 140 sqm/h |
| Quality | 30 sqm/h | 40 sqm/h | 50 sqm/h | 48 sqm/h |
| Resolutions | 2400 dpi Max | |||
| Media | ||||
| Print width | Maximum 1800 mm | |||
| Media specs |
Rigid and flflexiable materials; Front and back tables
|
|||
| Inks | ||||
| Type |
Environmental friendly UV/LED curable ink
|
|||
| Ink supply system |
2.5L Large Bulk System with automatic supply system
|
|||
| Colors |
CMYK Lc Lm Lk LLk W V/SS
|
|||
| Ink curing system |
LED UV Curing System
|
|||
| Operating environment | ||||
| Software |
Standard ( SAI photoprint ); Onyx , Caldera , Wasatch as optional
|
|||
| Connectivity |
USB 3.0/Ethernet
|
|||
| Power |
Single Phase , 220VAC±10 % , 50 / 60HZ ; 5000W ( Machine )
|
|||
| Environment |
Temp . 15-32°C; RH 40·65%
|
|||
| Dimensions & Weight | ||||
| Machine(L*W*H) |
3750*1280*1440mm
|
|||
| Package(L*W*H) |
3940*1390*1830mm (Machine); 2740*720*740 mm (Tables)
|
|||
